Home > Products > Water Filling Machine > 200ml-2L Small bottle water filling machine
This drinking water filling machine is for filling pure water into PET bottles. It can produce 24000 bottles of water per hour based on 500ml plastic bottle.The machine is suitable for different size of bottles,from 200ml to 2000ml.
1.Adopting direct connection between air conveyor and inlet star wheel which is easier for bottle changing.
2. Adopting clamp transferring technology. Bottle shapes are more varied, and the working table inside the machine is more laconic.
3. With little abrasion, stable transferring, easy to change bottles.
4.Stainless steel bottle clamp avoids a 2nd contamination.
5.With high filling speed and exact fluid level.
6.Excellent SS or food level plastic to liquid. Electric system is of international brand and achieves national food sanitary standard.
7.The bottle out star wheel is of screw down shape. No need to adjust transferring chain's height to different bottles.
| Model | XGF14-12-5 | XGF18-18-6 | XGF24-24-8 | XGF32-32-8 | XGF40-40-10 | XGF50-50-12 |
| Washing Heads | 14 | 18 | 24 | 32 | 40 | 50 |
| Filling Heads | 12 | 18 | 24 | 32 | 40 | 50 |
| Capping Heads | 5 | 6 | 8 | 8 | 10 | 12 |
| Capacity（b/h） | 5000 | 10000 | 12000 | 15000 | 20000 | 26000 |
| Power(kw) | 1.5 | 2.2 | 3 | 3 | 7.5 | 9 |
| Dimensions(mm) | 2200*1550*2450 | 2910*2150*2450 | 2850*2200*2450 | 3430*2630*2450 | 4300*2930*2450 | 5000*3840*2450 |
| Weight | 2000 | 2500 | 4200 | 6000 | 7000 | 9000 |
| Voltage | 380V | |||||
| Suitable Bottle Shape | circular,square | |||||
| Suitable caps | plastic screw cap | |||||
| Bottle Diameter(mm) | 50-100 | |||||
| Bottle Height(mm) | 150-310 | |||||
| Compressed Air Pressure(Mpa) | 0.3-0.7 | |||||
| Washing Medium | aseptic water | |||||
| Washing pressure(MPA) | 0.2-0.25 | |||||
